HT24

HT24

Technical Specifications

Ask for the product

Technical specification

  • Length:

  • 10 550 mm

  • Width:

  • 3 650 mm

  • Height:

  • 1 900-2 100 mm

  • Total weight:

  • 28 500 kg

  • Capacity of the working element:

  • 13,5 m3

  • Working unit lifting capacity:

  • 24 Mg

  • Power rating:

  • 168 kW

  • Exhaust gas purity class:

  • Stage V

  • Driving speed: (forward/reverse)

  • –

  • 1st gear

  • 4,0 km/h

  • 2nd gear

  • 8,0 km/h

  • 3rd gear

  • 15,0 km/h

  • 4th gear

  • 24,0 km/h
